Catalina 250 vs 2005 X-Yachts X-35 — Comparison
Catalina 250
2005 X-Yachts X-35
Specifications Side by Side
| Specification | Catalina 250 | 2005 X-Yachts X-35 |
|---|---|---|
| General | ||
| Manufacturer | Catalina | X-Yachts |
| Year | 1994–2004 | 2005–2014 |
| Type | Sloop | Sloop |
| Country | USA | Denmark |
| Designer | Gerry Douglas | Niels Jeppesen |
| Dimensions | ||
| LOA | 7.62 m (25.0 ft) | 10.59 m (34.7 ft) |
| LWL | 6.78 m (22.2 ft) | 9.40 m (30.8 ft) |
| Beam | 2.59 m (8.5 ft) | 3.30 m (10.8 ft) |
| Draft | 1.37 m (4.5 ft) | 2.10 m (6.9 ft) |
| Weight | ||
| Displacement | 1,588 kg (3,501 lbs) | 5,500 kg (12,125 lbs) |
| Ballast | 612 kg (1,349 lbs) | 2,000 kg (4,409 lbs) |
| Sailing | ||
| Sail Area | 24.5 m² (264 ft²) | 56.0 m² (603 ft²) |
| Hull Material | Fiberglass | Fiberglass |
| Keel Type | Fin | Fin |
| Engine & Tanks | ||
| Engine | 10 HP | 21 HP |
| Fuel Capacity | 30 L (7.9 gal) | 65 L (17.2 gal) |
| Water Capacity | 42 L (11.1 gal) | 130 L (34.3 gal) |
| Accommodation | ||
| Berths | 4 | 6 |
| Cabins | 1 | 2 |
Performance Comparison
Detailed Comparison
The Catalina 250 and 2005 X-Yachts X-35 represent two takes on sloop-rigged sailing. The Catalina 250 is a 1990s design by Catalina from USA, while the 2005 X-Yachts X-35 is a 2000s offering from X-Yachts from Denmark. The Catalina 250 was penned by Gerry Douglas. The 2005 X-Yachts X-35 was designed by Niels Jeppesen.
In terms of size, the Catalina 250 measures 7.62m (25.0ft) overall with a beam of 2.59m, compared to the 2005 X-Yachts X-35 at 10.59m (34.7ft) with a 3.30m beam. The 2005 X-Yachts X-35 is 2.97m longer than the Catalina 250. The 2005 X-Yachts X-35 displaces approximately 246% more than its counterpart, which significantly affects how each boat handles in different sea states.
Looking at performance, the Catalina 250 has good sail power for versatile performance with an SA/D ratio of 18.30 and 24.5 m² of sail area. The 2005 X-Yachts X-35, with an SA/D of 18.26 and 56.0 m² of canvas, offers good sail power for versatile performance. The Catalina 250 has the edge in terms of raw sailing performance.
For comfort and safety, the Catalina 250 offers a firm, racing-oriented motion (comfort ratio: 13.9) and excellent capsize resistance suitable for offshore voyaging (capsize ratio: 0.89). The 2005 X-Yachts X-35 has a comfort ratio of 18.1 and a capsize screening value of 0.75. The ballast ratios are 38.5% for the Catalina 250 and 36.4% for the 2005 X-Yachts X-35, reflecting their respective approaches to stability.
Below deck, the Catalina 250 provides 4 berths in 1 cabin with 42L of water capacity and 30L of fuel. The 2005 X-Yachts X-35 offers 6 berths in 2 cabins with 130L water and 65L fuel capacity.
Verdict
For cruising: The 2005 X-Yachts X-35 is the better choice for comfortable cruising thanks to its higher comfort ratio, offering a gentler motion at sea that crews will appreciate on longer passages.
For racing: The Catalina 250 has the performance advantage with its superior SA/D ratio, meaning more sail power relative to its displacement for competitive sailing.
For liveaboard: The 2005 X-Yachts X-35 offers more sleeping accommodation, making it better suited for extended living aboard. Consider water and fuel capacity for extended stays away from marinas.
