1963 Cal 40 vs 1976 C&C 33 — Comparison
1963 Cal 40
Specifications Side by Side
| Specification | 1963 Cal 40 | 1976 C&C 33 |
|---|---|---|
| General | ||
| Manufacturer | Cal | C&C Yachts |
| Year | 1963–1972 | 1976–1982 |
| Type | Sloop | Sloop |
| Country | USA | Canada |
| Designer | Bill Lapworth | Cuthbertson & Cassian |
| Dimensions | ||
| LOA | 12.19 m (40.0 ft) | 10.06 m (33.0 ft) |
| LWL | 9.14 m (30.0 ft) | 8.23 m (27.0 ft) |
| Beam | 3.35 m (11.0 ft) | 3.35 m (11.0 ft) |
| Draft | 1.83 m (6.0 ft) | 1.52 m (5.0 ft) |
| Weight | ||
| Displacement | 7,030 kg (15,498 lbs) | 4,536 kg (10,000 lbs) |
| Ballast | 2,722 kg (6,001 lbs) | 2,041 kg (4,500 lbs) |
| Sailing | ||
| Sail Area | 61.3 m² (660 ft²) | 42.0 m² (452 ft²) |
| Hull Material | Fiberglass | Fiberglass |
| Keel Type | Fin | Fin |
| Engine & Tanks | ||
| Engine | 22 HP | 15 HP |
| Fuel Capacity | 76 L (20.1 gal) | 57 L (15.1 gal) |
| Water Capacity | 114 L (30.1 gal) | 95 L (25.1 gal) |
| Accommodation | ||
| Berths | 6 | 6 |
| Cabins | 2 | 2 |
Performance Comparison
Detailed Comparison
The 1963 Cal 40 and 1976 C&C 33 represent two takes on sloop-rigged sailing. The 1963 Cal 40 is a classic design by Cal from USA, while the 1976 C&C 33 is a 1970s offering from C&C Yachts from Canada. The 1963 Cal 40 was penned by Bill Lapworth. The 1976 C&C 33 was designed by Cuthbertson & Cassian.
In terms of size, the 1963 Cal 40 measures 12.19m (40.0ft) overall with a beam of 3.35m, compared to the 1976 C&C 33 at 10.06m (33.0ft) with a 3.35m beam. The 1963 Cal 40 is 2.13m longer than the 1976 C&C 33. The 1963 Cal 40 displaces approximately 55% more than its counterpart, which significantly affects how each boat handles in different sea states.
Looking at performance, the 1963 Cal 40 has moderate sail power suitable for relaxed cruising with an SA/D ratio of 16.97 and 61.3 m² of sail area. The 1976 C&C 33, with an SA/D of 15.57 and 42.0 m² of canvas, offers moderate sail power suitable for relaxed cruising. The 1963 Cal 40 has the edge in terms of raw sailing performance.
For comfort and safety, the 1963 Cal 40 offers a moderate motion comfort level (comfort ratio: 21.4) and excellent capsize resistance suitable for offshore voyaging (capsize ratio: 0.70). The 1976 C&C 33 has a comfort ratio of 18.1 and a capsize screening value of 0.81. The ballast ratios are 38.7% for the 1963 Cal 40 and 45.0% for the 1976 C&C 33, reflecting their respective approaches to stability.
Below deck, the 1963 Cal 40 provides 6 berths in 2 cabins with 114L of water capacity and 76L of fuel. The 1976 C&C 33 offers 6 berths in 2 cabins with 95L water and 57L fuel capacity.
Verdict
For cruising: The 1963 Cal 40 is the better choice for comfortable cruising thanks to its higher comfort ratio, offering a gentler motion at sea that crews will appreciate on longer passages.
For racing: The 1963 Cal 40 has the performance advantage with its superior SA/D ratio, meaning more sail power relative to its displacement for competitive sailing.
For liveaboard: Both boats provide similar accommodation, making either a viable choice for living aboard. Consider water and fuel capacity for extended stays away from marinas.
